DELMADE 1150 Series Wheeled Offset Discs
Product Ref: p1-16
DELMADE 1150 Series is a Super Heavy Duty Wheeled Offset Disc engineered to exacting standards to ensure maximum reliability, longevity and performance in extreme conditions. This implement is designed for special purpose primary cultivation, or wherever a deep aggressive cut is required in conditions harsher than normal. It is ideal for forestry land-clearing operations, firebreaks, tillage of virgin uncultivated country, harsh stony environments or for special requirements such as sugar cane and similar crops in heavy or stony type soils. By utilising the finest high-strength materials available, along with innovative engineering and stringent quality control, an implement is achieved that is extremely strong, efficient, and ultra-reliable.
Product Highlights:
- Oil Bath Bearings
- Australian Made
- 12 Month Warranty
- Powder Coat Finish - with zinc undercoat
Specifications
The legendary reliability of the Delmade Offset Discs is not a myth.
The very first Delmade Disc was built with an expertly engineered frame, combined with a rugged gang axle system and fitted with the renowned Delmade Disc Bearing System. Years later, after ploughing thousands of acres, that pioneer disc is still going strong. In fact, it still has its original bearings!
| No. of Plates | Product Code | Plate Size* | No. of Bearings | No. of Axles | Working Width | Hp Requirement | Transport Width | Weight per Disc | Total Weight | Axle Size | Disc Spacing | ||||
| Metric (mm) | Imperial | Metric (m) | Imperial | Metric (m) | Imperial | Metric (m) | Imperial | ||||||||
| N20 | DOD1415 | 810x10 | 32"x3/8" | 8 | 4 | 3.3 | 10' 10" | 210+ | 3.48 | 11' 5' | 275 | 5500 | 54 | 2 1/8" | 13" |
| 24 | DOD1420 | 810x10 | 32"x3/8" | 8 | 4 | 4.0 | 13’ | 240+ | 4.13 | 13’7” | 254 | 6100 | 54 | 2 1/8" | 13" |
| 28 | DOD1425 | 810x10 | 32"x3/8" | 8 | 4 | 4.6 | 15’2” | 280+ | 4.81 | 15’10” | 233 | 6530 | 54 | 2 1/8" | 13" |
| 32 | DOD1437 | 810x10 | 32"x3/8" | 12 | 6 | 5.3 | 17’4” | 320+ | 5.47 | 18’ | 222 | 7090 | 54 | 2 1/8" | 13" |
| 36 | DOD1435 | 810x10 | 32"x3/8" | 12 | 6 | 5.9 | 19’6” | 360+ | 6.14 | 20’2” | 209 | 7520 | 54 | 2 1/8" | 13" |
* 810x12mm (32"x1/2") Disc Plates also available on request
Features:
-
- Large Spacing
- Very high weight per disc ratio up to 254kg per disc
- 32 plate folding 5.28m/17 1/4" working width, 3.5m transport width
- 4.15m to 6.14m transport width
- Oil bath bearings with duo cone seals, built to Delmade specifications, give extreme reliability, low maintenance and maximum longevity
- Large 2 1/8" dia HT gang nuts
- Capped and locked gang nuts
- Hydraulic pole adjustment with gas accumulator
- Large single 600/50 x 22.5 flotation tyres for transport
- Depth gauge
- Horsepower requirements from 240+
- Australian designed and built for extreme Australian conditions
 |
.jpg) |
 |
| Gang axle nut complete with cap and locking washer | Hydraulic cylinder transport locks | Depth gauge |
 |
 |
 |
| Parallel lift | Rear draw bar | Legendary Delmade oil bath bearings |
Reviews
Do you own this product?
Let us know what you think!
The big tyres are great for flotation in fact the Disc will float out my tractor. Before buying we looked at the Delmade first and we said, "They're a beautiful set of discs." Then we went away and looked at everything else. Then we came back to Delmade... I've used and seen a lot of other Discs in my day and most have broken poles and weld on the frames, but I've had my Delmade's for 9 1/2 years and have never repaired the frame once. We replaced 5 sets of disc plates on the original set of bearings! There's not a set of discs out there that match them. Today we own three Delmade Disc and we are very happy with them all. 2 x 1050 48 plate and 1 x 1150 24 plate.
Phillip Fish
Contractor - P.R. Fish & Sons Pty Ltd - Owner of 3 Delmade Offsets
